1969 Ferrari 312 P
The new 1971 version of the sports prototype came with a flat-12 engine, often referred to as a boxer engine.
Many publications added the letter B after the P of its name to indicate its engine type, but this variation was never officially sanctioned by Ferrari which simply called it the 1971 312 P.
In addition to a new engine, the chassis also differed in certain respects as aluminium panels were riveted to the small-diameter tubular spaceframe a further step towards the monocoque.
Ferrari 312 P Technical Specifications
Year of Manufacture – 1969
ENGINE | ||
type | rear, longitudinal flat-12 | |
bore/stroke | 78.5 x 51.5 mm | |
unitary displacement | 249.25 cc | |
total displacement | 2991.01 cc | |
compression ratio | 11,5:1 | |
maximum power | 331 kW (450 hp) at 10.800 rpm | |
power per litre | 150 hp/l | |
maximum torque | – | |
valve actuation | twin overhead camshaft per bank, four valves per cylinder | |
fuel feed | Lucas indirect injection | |
ignition | single spark plug per cylinder, electronic | |
lubrication | dry sump | |
clutch | multi-plate | |
CHASSIS | ||
frame | tubular steel | |
front suspension | independent, unequal-length wishbones, coil springs, telescopic shock absorbers, anti-roll bar | |
rear suspension | independent, unequal-length wishbones, coil springs, telescopic shock absorbers, anti-roll bar | |
brakes | discs | |
transmission | 5-speed + reverse | |
steering | rack-and-pinion | |
fuel tank | capacity 117 litres | |
front tyres | 9-22-13 | |
rear tyres | 13-26-15 | |
BODYWORK | ||
type | two-seater spider | |
length | 3500 mm | |
width | 1880 mm | |
height | 956 mm | |
wheelbase | 2220 mm | |
front track | 1425 mm | |
rear track | 1400 mm | |
weight | 585 kg (with liquids) | |
PERFORMANCE | ||
top speed | 320 km/h | |
acceleration 0-100 km/h | – | |
0-400 m | – | |
0-1000 m | – |
